MIL-F-24666(SH)
3.3 Design and construction.
Seals shall be synthetic rubber in accordance with MIL-R-7362.
3.3.1
Seals.
Filter elements shall be as shown on figure 1 and
3.3.2 Filter elements.
as specified herein. Gaskets shall prevent cocking of the element during instal-
lation. Filters shall be the full-flow type rated at 50 gallons per minute
(gal/min) with flow through the element from "outside-in". The design shall be
such that the filter element cannot be installed in reverse.
3.4 Performance.
3.4.1 Coalescer protection. When tested in series with referee coalescer
elements (4.7.3) in a filter/separator and subjected to the tests specified in
4.7.3.1, the pre-filter performance shall be as specified in table I.
3.4.2 Element pressure drop. The pressure drop through an as received
clean element using MIL-H-5606 at rated flow of 50 gal/rein shall not exceed
4 pounds per square inch
at 100 degrees Fahrenheit (°F)
5°F.
3.4.3 Element collapse. The elements shall withstand 180
differential pressure when tested by the procedure in 4.7.5 without evidence
of structural degradation.
Element dirt capacity shall be a minimum of
3.4.4 Element dirt capacity.
190 grams of Air Cleaner Fine Test Dust (ACFTD) to a differential pressure of
differential, and 210 grams of ACFTD to a differential pressure of 30
15
differential, across the filter element tested by the procedure described
No clean-up filter shall be used.
in 4.7.6.
3.4.5 Flow fatigue. The elements shall withstand the flow fatigue cycles
Element integrity shall be established by measurement of
specified in 4.7.7.
filtration efficiency ratios (see 4.7.7.2).
3.4.6 Fabrication integrity. The minimum bubble point values shall be
established by the filter manufacturer which will yield elements that will fully
meet all the requirements of this specification. Elements submitted to the
quality conformance bubble test shall meet the minimum values established herein.
The filter element shall operate throughout a
3.5 Temperature range.
temperature range of 40 to 160°F.
4
