MIL-DTL-24402/5B(SH)
.687
DIA
.686
.576
DIA
.574
.210
.149
.220
.159
.554
SEE DETAIL A
.900
.950
MAX
.094
FOR AS3209-014 O-RING
.104
.513
CONTR
DIA
.511
OPTION
.624
DIA
.623
.010
ALL EDGES .020 RADIUS
M8791/1-015 BACK-UP RING
AS3209-015 O-RING
DETAIL A
FIGURE 2. Male gland dimensions.
CHANGES FROM PREVIOUS ISSUE. Marginal notations are not used in this revision to identify changes with
respect to the previous issue due to the extent of the changes.
Preparing activity:
Navy SH
(Project 4330-2013-014)
NOTE: The activities listed above were interested in this document as of the date of this document. Since
organizations and responsibilities can change, you should verify the currency of the information above using the
ASSIST Online database at https://assist.dla.mil.
4
