MIL-DTL-24402/1A
2.50 RAD
6.00
MAX
DIFFERENTIAL PRESSURE
INDICATOR TO BE WITHIN
2.50 RAD OF CENTER
6.00±.03
SAE J1926-16 STRAIGHT THD
INLET AND OUTLET PORTS
DIFFERENTIAL PRESSURE
INDICATOR TO BE WITHIN
THIS AREA
1.13±.06
3.66
MAX
2.75±.03
OUTLET
PORT
1.75
MAX
INLET
DRILL .406±.015
PORT
DIA THRU HOLE,
2 PLACES
2.25±.03
4.50±.03
11.75
MAX
13.50
MAX
14.25
MAX
USER SHALL
PROVIDE
CLEARANCE
FOR ELEMENT
REMOVAL
ELEMENT REMOVAL
4.75 DIA
MAX
CLEARANCE
FIGURE 2. Single-element (size C) filter housing outline dimensions.
5
